SOLO CON CAVO ROSSO COMELIT 2E7T000500
ONLY WI TH COMELIT RED CABLE 2E7T00 0500
FIXED PO E SETTABLE POE NO POE
HOME 1 HO ME 2 HOME 3 H OME 4
Description
Article 1456 / 1456S is a single-apartment gateway that:
• can serve up to a maximum of 15 slave devices connected to the apartment;
• answer calls from a external unit via a virtual door entry monitor App for smart phone/tablet or using a normal GSM or
landline telephone;
• incorporates the SIP protocol to enable telephone calls via SIP server or via virtual lines purchased from a SIP services
provider;
• can be configured remotely from a web interface;
• in the master version (Art. 1456), does not require door entry monitors to be connected.
1. Ethernet port for ViP system riser input (default addressing: “Autoip”).
2. Dip switches for the procedures “Reboot with predetermined network settings” and “Restoring factory settings”.
3. Power supply input via Art. 1441, Art. 1441B.
4. CV1 and CV2 for setting port HOME2.
5. CV3 and CV4 for setting port HOME3.
6. HOME4 non POE Ethernet port for PC or router connection (default: “Static IP address” 192.168.1.200, netmask
255.255.255.0).
7. HOME3 “POE” settable Ethernet port non POE (default: “Static IP address” 192.168.1.200, netmask 255.255.255.0).
8. HOME2 “POE” settable Ethernet port non POE (default: “Static IP address” 192.168.1.200, netmask 255.255.255.0).
9. HOME1 Ethernet port “POE” (default: “Static IP address” 192.168.1.200, netmask 255.255.255.0).
With port “POE” DO NOT use standard Ethernet to connect to the router or to the PC; use only the red
Comelit cable Art. 1449 to connect to the router or to the PC.
