Comelit 1456 - Kit System

8
FLOOR VIP SYSTEM GAT E WAY
SOLO CON CAVO ROSSO COMELIT 2E7T000500
ONLY WI TH COMELIT RED CABLE 2E7T00 0500
FIXED PO E SETTABLE POE NO POE
HOME 1
VIP SYSTE M
HO ME 2 HOME 3 H OME 4
Art.1456
HOME INTERFACE
STATIC IP ADDRESS
192.168.1.200 (default)
see page 5
ROUTER
Art.1441
Art.1441B
Installer PC
ViP SYSTEM
INTERNET
SIP
PROVIDER
All system devices form part of a single network, so it it is only necessary to configure interface HOME.
In this case, DO NOT alter the configuration of interface VIP SYSTEM.
KIT SYSTEM
