This function can be used to select the manual
switchboard calling mode, from the 3 options
available:
1- SIMPLEBUS CODE (default), the call is made by
entering the code corresponding to each user.
• If the system is a SIMPLEBUS type, the door-entry
phone user is identied by a User Name eld
(optional) and a Code eld no longer than 3 digits
(between 1 and 240).
EXAMPLE: User name = Smith; Code = 015.
• If the system is a SIMPLEBUS TOP type, the door-
entry phone user is identied by the User Name
eld (optional) and a Code eld consisting of two
parts: zone eld with no more than 3 digits (between
1 and 500) and a user eld which must have 3
digits (between 1 and 249).
EXAMPLE: User name = Smith; Code = 25 015.
2- INDIRECT CODE (the call takes place by entering
the indirect code with 6 digits. This code must be
stored in the memory and associated with the user
who has been given a name (compulsory) and
Simplebus or Simplebus TOP code).
3- INDIRECT CODE WITHOUT NAME, see previous
mode; the difference is that in this case the name
eld is not compulsory. In this mode, FILTER OFF
or FILTER ON will be requested; if activated only
named users will appear on the display; however, if
the lter is deactivated, all users will be displayed.
To activate the function:
- press the MENU key and use the keys to view
the 8-ADVANCED OPTIONS menu, then press 8;
8-ADVANCED
OPTIONS
- use to view the 2-CALLING MODE menu, then
press 2;
2-CALLING
MODE
- view the selected mode using the keys, then
press 1 for the SIMPLEBUS CODE, press 2 for
the INDIRECT CODE or 3 for the INDIRECT CODE
WITHOUT NAME;
*1-SB CODE
2-INDIRECT CODE
3-INDIRECT CODE
WITHOUT NAME
- if the 3-DIRECT CODE WITHOUT NAME is selected,
lter activation is requested; press 1 to disable it, or 2
to activate it;
*1-FILTER OFF
2-FILTER ON
This is disabled by default.
Activating this function will allow you to make a video
call to an internal unit. The monitor called by the
switchboard will switch on, making it possible to view,
for example, the images from the remote cameras
connected to Art. 1259/A or Art. 1259C (see FT/
SB/13 or FT/SBC/05).
VIDEO mode can be NORMAL or DIRECT.
In NORMAL mode, the internal unit video feed
begins when the handset is lifted, or when the
audio line is activated in receipt of a call from the
switchboard; in DIRECT mode, on the other hand, it
begins automatically on receipt of a call.
CAUTION! For DIRECT mode to operate correctly,
the system must be tted with TOP brackets,
door-entry phones, switching devices and mixers
(see “TABLE OF SIMPLEBUS TOP PRODUCTS”,
page 42).
To activate the function:
- press the MENU key and use the keys to view
the 8-ADVANCED OPTIONS menu, then press 8;
8-ADVANCED
OPTIONS
1-VIDEO MODE
CONFIGURATION
- press 1 to activate or deactivate the function;
SERVICE
ACTIVE
SERVICE
NON ACTIVE
- if the service has been activated, you will be asked
to select one of the 2 modes.
Press 1 for NORMAL MODE or 2 for DIRECT MODE;
* 1- NORMAL MODE
2- DIRECT MODE
C8.1 - Video mode configuration
(available from R.I.006)
C8.2 - Calling mode (available from R.I.006)
