Comelit UT1020 - Smart Call Address Programming

21
Smart programming of consecutive addresses
LL
1
S1 S2
8
8765
default
OFF
8765
ON
9
DIP 6: configuring
button type:
Single button (DIP6
ON).
Dual button (DIP6
OFF, default).
OFF
ON
1 2 3 4 6 75 8
4
S1 S2
3
ON
1 2 3 4 6 75 8
5
example:
code 1
Set the address of the apartment you
wish to call (for example:1) using
the DIP-switches (see “Addressing
table” )
8765
default
OFF
8765
ON
2
DIP 6: configuring
button type:
Single button (DIP6
ON).
Dual button (DIP6
OFF, default).
=
1
6
= 2
+1
= 3
+1
= 4
+1
= 5
+1
7
Press the button you want to
associate with the call address set
using the DIP-switches
Press the following buttons
to assign consecutive addresses.
