Comelit UT1020 - Special Programming Reference Tables

24
CODE DIP SWITCHES ON FUNCTIONS
Audio-visual messages
195 1,2,7,8 Hebrew
196 3,7,8 Polish
197 1,3,7,8 Catalan
198 2,3,7,8 Galician
199 1,2,3,7,8 Basque
206 2,3,4,7,8 Danish
207 1,2,3,4,7.8 Norwegian
211 1,2,5,7,8 Swedish
215 1,2,3,5,7.8 Italian
216 4,5,7,8 French
217 1,4,5,7,8 Spanish
218 2,4,5,7,8 Dutch
219 1,2,4,5,7.8 Greek
220 3,4,5,7,8 English
221 1,3,4,5,7.8 German
222 2,3,4,5,7.8 Portuguese
202 2,4,7,8 Enables voice message (door opened warning) when the RTE contact is closed
203 1,2,4,7,8
Disables voice message (door opened warning) when the RTE contact is closed
(default setting)
210 2,5,7,8 Enables visual messages and disables voice messages (default)
214 2,3,5,7,8 OFF: disables voice and visual messages
Actuator command management
N.B. Art. 1256 in generic actuator mode must not be present in the system.
229 1,3,6,7,8 C.NC.NO relay activation on actuator command: 2 sec (default)
230 2,3,6,7,8 C.NC.NO relay activation on actuator command: 4 sec
231 1,2,3,6,7.8 C.NC.NO relay activation on actuator command: 8 sec
Door lock
223 1,2,3,4,5,7,8
Door lock command on SE in AC
(default)
224 6,7,8 Door lock command on SE in enhanced AC
225 1,6,7,8 Door lock command on SE in DC
241 1,5,6,7,8
Management of internal units connected to Art. UT1020: up to 70
(default)
242 2,5,6,7,8 Management of internal units connected to Art. UT1020: from 71 to 100
184 4,5,6,8 Door lock time: 100 msec
185 1,4,5,6,8 Door lock time: 200 msec
186 2,4,5,6,8 Door lock time: 500 msec
245 1,3,5,6,7.8 Door lock time: 2 sec + disabling tone (default)
246 2,3,5,6,7.8 Door lock time: 4 sec
247 1,2,3,5,6,7,8 Door lock time: 8 sec
248 4,5,6,7,8 Door lock confirmation tone: enabled
252 3,4,5,6,7.8 Lock-release always enabled (default)
253 1,3,4,5,6,7,8 Lock-release only enabled for user called
System functions
232 4,6,7,8 Awaiting response time: 60 sec (default)
233 1,4,6,7,8 Awaiting response time: 120 sec
234 2,4,6,7,8 Awaiting response time: 30 sec
235 1,2,4,6,7.8 Talk time: 90 sec (default)
236 3,4,6,7,8 Talk time: 180 sec
145 1,5,8 RTE input set as local lock-release input (default)
146 2,5,8 RTE input set as door open indication
Special programming table
