Technical specifications
Art. UT1020
GENERAL DATA
Type Modular
Product height (mm) 90
Product width (mm) 100
Product depth (mm) 35
Product weight (g) 275
Product colour Black RAL9005, Transparent, Aluminium
Coating material type Polycarbonate, Aluminium alloy
Flush mounting Yes, with specific accessory
Surface mounting Yes, with specific accessory
COMPATIBLE SYSTEMS
Simplebus 2 audio/video with
power supply unit art. 4888C
Yes
AUDIO SPECIFICATIONS
Microphone MEMS digital audio sensor, omnidirectional
Loudspeaker 28 mm (Ø), 8 Ohm, 1W (2)
Technologies implemented Full-Duplex
CAMERA FEATURES
Camera Colour
Sensor type 1/3" CMOS
Lens (mm) 1.79
Viewing angle (H x V - °) 120 x 90
Sensitivity (lux) 0.45
Resolution (H x V - pixel) 1288 x 968
ELECTRICAL SPECIFICATIONS
Type of power supply External power supply
Power supply voltage 33 VDC
Absorption in standby (W) 1.5
Maximum absorption (W) 6
HARDWARE CHARACTERISTICS
Call type Buttons
Type of buttons Mechanical
Number of buttons (no.) 2
Backlighting colour White, O
Terminals L L V+ V- COM NC NO SE GND RTE TX- TX+ RX- RX+
Number of inputs (no.) 1
Number of outputs (no.) 2
Output type Relay (C-NO-NC, 4A@12-24 VAC/VDC, inrush current 10A)
Communication port Micro-USB
Twilight sensor Yes
SETTINGS
Loudspeaker volume Yes
Mic volume Ye s
Backlighting brightness Ye s
PROGRAMMING MODE
Manual (by means of Dip Switch) Ye s
ViP Manager software Yes
ENVIRONMENTAL AND CONFORMITY
SPECIFICATIONS
IP protection rating (when installed) IP65
IK anti-vandal protection rating IK08
Operating temperature (°C) -25 to 55
Operating humidity (max RH - %) 25 to 95
Environmental class IV
Conformity and Certifications
RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU (EN 61000-6-
1:2007, EN 61000-6-3:2007+A1:2011)
MAIN FUNCTIONS
Lock-release Ye s
Number of auxiliary relays (no.) 1
Input for local key button Yes
Input for door open signal Ye s
System status visual indications Yes
System status audio indications Yes
System status voice synthesis Yes
