Comelit UT1020 - Installation Options Overview; Flush-Mounted Installation Components; Surface-Mounted Installation Components

9
Installation
Flush-mounted box
3110/1
3110/1A
3110/2
3110/2A
3110/3
3110/3A
3110/4
3110/4A
Rain shield
UT9181 UT9182 UT9184H UT9183 UT9186 UT9189 UT9184 UT9188
Module holder/ finishing frame
UT9161 UT9162 UT9163 UT9164
Rain shield UT9191 UT9192 UT9194H UT9193 UT9196 UT9199 UT9194 UT9198
Housing/frame UT9171 UT9172 UT9174H UT9173 UT9176 UT9179 UT9174 UT9178
Optional
The entrance panel is available in flush-mounted or surface-mounted variants:
Flush-mounted installation composition table
Surface-mounted installation composition table
A = Rain shield
B = Surface-mounted housing with frame
A = Flush-mounted box
B = Rain shield
C = Flush-mounted module holder with finishing frame
