Comelit UT1020 - Specific Call Address Programming

22
LL
1
8765
default
OFF
8765
ON
2
DIP 6: configuring
button type:
Single button (DIP6
ON).
Dual button (DIP6
OFF, default).
OFF
ON
1 2 3 4 6 75 8
4
S1 S2
3
ON
1 2 3 4 6 75 8
5
example:
code 25
Set the address of the apartment you
wish to call (for example:25) using
the DIP-switches (see “Addressing
table” )
S1 S2
8
8765
default
OFF
8765
ON
9
DIP 6: configuring
button type:
Single button (DIP6
ON).
Dual button (DIP6
OFF, default).
=
25
6
ON
1 2 3 4 6 75 8
ON
1 2 3 4 6 75 8
ON
1 2 3 4 6 75 8
37
70
58
7
Press the button you want to
associate with the call address set
using the DIP-switches
Repeat steps 4 and 5 to assign a specific address to each button
example: code 37 example: code 70 example: code 58
Programming of specific addresses
