Comelit UT2020 - Button Module Connection (UT9200); Touchscreen Module Connection (UT9270); Variant with Separate Power Supply

19
-
+
120-230 V
1595
1210A
1210
E
T
R
GND
SE
-
SE
+
NO NC
C
O
M
LL
+
VV
-
J4
UT9270
> 8O utenti
UT2020 UT2010VC
12 VAC/VDC
18 Ω MAX
1210A
1210
UT9270
E
T
R
GND
SE
-
SE
+
NO NC
C
O
M
LL
+
VV
-
8O utenti
massimo
UT2020 UT2010VC
12 VAC/VDC
18 Ω MAX
UP
NERO
ROSSO
MAX 8
1210A
1210
UT9200
E
T
R
GND
SE
-
SE
+
NO NC
C
O
M
LL
+
VV
-
UT2020 UT2010VC
12 VAC/VDC
18 Ω MAX
Connection of button modules art. UT9200
Connection of Touchscreen module art. UT9270
Variant with separate power supply
Max 20 m. Local door-opener button.
Max 8 modules (Max 30 modules with additional power supply).
Max 20 m. Local door-opener button.
For systems with over 80 users, provide an additional power supply
RED
BLACK
Maximum
80 users
> 80 users
