Comelit UT2020 - Maximum System Expansion; Maximum Expansion Per Apartment

35
Maximum system expansion
Devices
6701W(/BM)
6701W/8
6721W(/BM)
6601W(/BM)
6801W(/BM)
6741W(/BM)
Maximum number of door
entry monitors that can be
powered from art. 1210A
100 100 90 100
100
(Building mode)
10
(Kit mode)
Call repetition devices that can
be used
1229A 1229A
1229A
1229
1229A
1229
1229A
Devices
6701W(/BM)
6701W/8
6721W(/BM)
6601W(/BM)
6801W(/BM)
6741W(/BM)
Maximum number of internal
units (including call repetition
devices) with the same user
code
4 4 4 4
1
Maximum number of main
door entry monitors powered
from the riser
1 1 1 1 1
Maximum number of main
door entry monitors that can
be powered by Art. 1212/B
/ / 3 3 /
Maximum expansion per apartment
For further information, refer to the manual for Art. 6741W
For installation information and limits, consult the relevant manual
A single 6741W(/BM) door entry monitor can be installed for each user code; this will also be the only main door entry
monitor.
In Building mode: up to 3 secondary door entry monitors can also be added (6701W (/BM), 6701W/8, 6721W (/BM), 6801W (/
BM), 6601W (/BM)).
In Kit mode: up to 1 door entry monitor can also be added (6701W (/BM), 6701W/8, 6721W (/BM), 6801W (/BM), 6601W (/
BM)).
