Chapter 3 General Information
3.1Top Panel
=
Figure 3-1 Main Unit
Product Information:
1) Logo
2) Model
CM300
3) Brand Name
Three-channel Electrocardiograph
4) Classification Symbol
Equipment of CF type with defibrillator proof
LCD Screen
Control Panel
Recorder
RS232 Interface
External Input
/Output socket
Patient Cable Socket
Logo and Model
USB socket
