When it is set as 6×2+1R, 12 leads of average template waveforms are recorded in 6 channels and 2
sequences and add 1 average template waveform of the rhythm lead.
When it is set as “Off”, there is no average template output.
(6) SAVE OPTIONS: Save only, Print&Save, off
When the storage option is set as “Save only”, the ECG data recorded under the automatic working mode
will be stored in the document management “File” interface automatically.
When the storage option is set as “Print&Save”, the ECG data recorded under the automatic working mode
will be pinrted out , and stored in the document management “File” interface automatically in the same
time.
When the storage option is set as “off”, the ECG data recorded under the automatic working mode will not
be stored in the document management “File” interface.
(8) PAPER TYPES: rolled ,folded .
There are two kinds of record paper supported by the twelve-channel electrocardiograph: rolled
thermosensitive record paper and folded thermosensitive record paper. When no record paper is loaded or
the record paper is used up, “Lack of Paper” will display on the LCD screen to remind the user of loading
or replacing the record paper.
Note: If incorrect paper type is selected, the equipment may not print normally.
Types and Specifications of the Paper: specification of the rolled paper: 80mmx20m; specification of the
folded paper: 80mmx20m
(9) PRINTER TEST: Off, testing. In the print head test the triangle wave is printed normally.
WARNING : When the printer is abnormal, it must be maintained by the qualified engineer.
The modification and maintenance should be conducted by the personnel authorized by the Our
Company; otherwise Our Company will not be responsible for the safety, reliability and
performance of the instrument.
5.6.4 SYSTEM Settings
Press the MENU key to enter the “Setting” menu, select the “System Options” as shown in the following
figure:
