COMENDA AC2P Series User Manual

User instructions
EN
DISPLAY - TEMPERATURE PROBES DISPLAY
1. SUPPLY WATER TEMPERATURE PROBE 2. PRE-WASH TEMPERATURE PROBE 3. TEMPERATURE PROBE 1ST WASH 4. / 5. / 7. RINSE TEMPERATURE PROBE
MACHINE OFF MACHINE IGNITION TANK FILLING FIRST SPEED SECOND SPEED
TEMPERATURE DISPLAY TEMPERATURE PROBE ALARM TEMPERATURE DISPLAY BUTTON
H01 - LIGHT: MACHINE ENERGISED H02 - LIGHT: TANKS FULL H03 - LIGHT: CUT-OUT SWITCH ACTIVATED S1 - START/STOP BUTTON SAT - AUTOTIMER ON/OFF BUTTON FIRST SPEED PWS ACTIVATION BUTTON (OPTIONAL)
CONTROL PANEL DESCRIPON
01 02 03 04
06 05
S26 - BUTTON (OPTIONAL):
• SELF-CLEANING AND DRAIN CYCLE • SELF-CLEANING CYCLE • DRAIN CYCLE
HAT - LIGHT: AUTOTIMER ACTIVE H26 - LIGHT: SELF-CLEANING OR DRAIN CYCLE ACTIVE
17
