F80CTL & G80CTL: Installation, Start–Up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
30
Table 13 – Air Delivery - CFM (With Filter)
(SW1-5 and SW4-3 set to OFF, except as indicated. See Footnotes
1
and
2
)
Unit Size:0451712 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 525 540 540 550 550
See Note
4
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 525 540 540 550 550
See Note
4
OFF ON OFF 700 720 715 730 735 745 745 745 735 725
OFF ON ON 885 905 920 925 920 910 905 900 895 885
ON OFF OFF 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
ON OFF ON 1250 1265 1275 1280 1275 1265 1255 1240 1205 1170
ON ON OFF 1425 1425 1410 1380 1340 1305 1270 1235 1200 1165
ON ON ON 1425 1425 1410 1380 1340 1305 1270 1235 1200 1165
Maximum Clg Airflow
2
1480 1445 1415 1380 1345 1310 1275 1235 1200 1165
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 525 540 540 550 550
See Note
4
Continuous Fan
Airflow (SW3)
OFF OFF ON 525 540 540 550 550
See Note
4
OFF ON OFF 700 720 715 730 735 745 745 745 735 725
OFF ON ON 885 905 920 925 920 910 905 900 895 885
ON OFF OFF 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
ON OFF ON 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
ON ON OFF 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
ON ON ON 1070 1080 1085 1095 1095 1100 1095 1090 1080 1070
Heating (SW1)
High Heat Airflow
3
730 730 735 750 765 770 770 770 760 750
Low Heat Airflow
3
605 625 635 630 635 635 630 625 615 605
Unit Size: 0701412 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1050 1050 1050 1050 1050 1050 1045 1035 1020 1000
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 515 500 500 490 485
See Note
4
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 515 500 500 490 485
See Note
4
OFF ON OFF 690 680 675 680 675
See Note
4
OFF ON ON 875 875 875 870 865 855 850 835 825 820
ON OFF OFF 1050 1050 1050 1050 1050 1050 1045 1035 1020 1000
ON OFF ON 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
ON ON OFF 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
ON ON ON 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
Maximum Clg Airflow
2
1395 1400 1400 1400 1395 1385 1370 1340 1300 1245
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 515 500 500 490 485
See Note
4
Continuous Fan
Airflow (SW3)
OFF OFF ON 515 500 500 490 485
See Note
4
OFF ON OFF 690 680 675 680 675
See Note
4
OFF ON ON 875 875 875 870 865 855 850 835 825 820
ON OFF OFF 1050 1050 1050 1050 1050 1050 1045 1035 1020 1000
ON OFF ON 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
ON ON OFF 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
ON ON ON 1220 1225 1225 1225 1225 1220 1205 1190 1185 1170
Heating (SW1)
High Heat Airflow
3
1160 1165 1175 1180 1180 1180 1180 1180 1180 1175
Low Heat Airflow
3
735 735 735 735 725
See Note
4
