Comfortmaker F80CTL User Manual

F80CTL & G80CTL: Installation, Start–Up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
33
1. Nominal 350 CFM/ton cooling airflow is delivered with SW1-5 and SW4-3 set to OFF.
Set SW1-5 to ON for nominal 400 CFM/ton (+15% airflow).
Set SW4-3 to ON for nominal 325 CFM/ton (-7% airflow).
Set both SW1-5 and SW4-3 on ON for nominal 370 CFM/ton (+7% airflow).
This applies to Cooling and Low-Cooling airflow, but does not affect continuous fan airflow.
The above adjustments in airflow are subject to motor horsepower range/capacity.
2. Maximum cooling airflow is achieved when switches SW2-1, SW2-2, SW2-3 and SW1-5 are set to ON, and SW4-3 is set to OFF.
3. All heating CFM's are when comfort/efficiency adjustment switch (SW1-4) is set to OFF
4. Ductwork must be sized for high-heating CFM within the operational range of ESP. Operation within the blank areas of the chart is not recommended because high-heat operation will be
above 1.0 ESP.
5. All airflows on 21" casing size furnaces are 5% less on side return only installations.
(SW1-5 and SW4-3 set to OFF, except as indicated. See Footnotes
1
and
2
)
Unit Size: 1102120 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1750 1750 1750 1750 1750 1750 1750 1750 1740 1725
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default:
OFF OFF OFF 875 875 875 875 875 See Note
4
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 700 700 700 700 700 See Note
4
OFF ON OFF 875 875 875 875 875 See Note
4
OFF ON ON 1050 1050 1050 1050 1050 See Note
4
ON OFF OFF 1225 1225 1225 1225 1225 1225 1225 1225 1225 1225
ON OFF ON 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
ON ON OFF 1750 1750 1750 1750 1750 1750 1750 1750 1740 1725
ON ON ON 2100 2100 2100 2100 2090 2075 2055 2040 2005 1970
Maximum Clg Airflow
2
2200 2190 2190 2180 2155 2145 2125 2100 2080 2020
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default:
OFF OFF OFF 875 875 875 875 875 See Note
4
Continuous Fan
Airflow (SW3)
OFF OFF ON 700 700 700 700 700 See Note
4
OFF ON OFF 875 875 875 875 875 See Note
4
OFF ON ON 1050 1050 1050 1050 1050 See Note
4
ON OFF OFF 1225 1225 1225 1225 1225 1225 1225 1225 1225 1225
ON OFF ON 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
ON ON OFF 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
ON ON ON 1400 1400 1400 1400 1400 1400 1400 1400 1400 1400
Heating (SW1)
High Heat Airflow
3
1460 1465 1475 1475 1475 1475 1475 1475 1465 1465
Low Heat Airflow
3
1275 1295 1315 1320 1320 1320 1320 1320 1320 1315
Unit Size: 1352422 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1750 1765 1765 1775 1780 1785 1785 1775 1770 1765
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 860 880 895 900 905 900 890 865 845 825
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 690 710 715 710 690 See Note
4
OFF ON OFF 860 880 895 900 905 900 890 865 845 825
OFF ON ON 1015 1050 1070 1080 1085 1095 1095 1090 1085 1075
ON OFF OFF 1185 1220 1245 1260 1270 1275 1280 1280 1285 1280
ON OFF ON 1400 1415 1420 1425 1425 1420 1415 1410 1400 1390
ON ON OFF 1750 1765 1765 1775 1780 1785 1785 1775 1770 1765
ON ON ON 2080 2095 2100 2110 2105 2115 2125 2115 2120 2090
Maximum Clg Airflow
2
2240 2255 2265 2270 2265 2255 2220 2175 2135 2085
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 860 880 895 900 905 900 890 865 845 825
Continuous Fan
Airflow (SW3)
OFF OFF ON 690 710 715 710 690 See Note
4
OFF ON OFF 860 880 895 900 905 900 890 865 845 825
OFF ON ON 1015 1050 1070 1080 1085 1095 1095 1090 1085 1075
ON OFF OFF 1185 1220 1245 1260 1270 1275 1280 1280 1285 1280
ON OFF ON 1400 1415 1420 1425 1425 1420 1415 1410 1400 1390
ON ON OFF 1400 1415 1420 1425 1425 1420 1415 1410 1400 1390
ON ON ON 1400 1415 1420 1425 1425 1420 1415 1410 1400 1390
Heating (SW1)
High Heat Airflow
3
1825 1835 1850 1855 1860 1860 1855 1850 1845 1840
Low Heat Airflow
3
1645 1660 1670 1675 1675 1675 1675 1670 1665 1660
Table 13 – Air Delivery - CFM (With Filter) (Continued)
