F80CTL & G80CTL: Installation, Start–Up, Operating and Service and Maintenance Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
32
(SW1-5 and SW4-3 set to OFF, except as indicated. See Footnotes
1
and
2
)
Unit Size: 0901716 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1350 1370 1390 1390 1400 1390 1380 1380 1360 1340
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 680 680 680 675 670
See Note
4
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 525 520 525 495 475
See Note
4
OFF ON OFF 680 680 680 675 670
See Note
4
OFF ON ON 815 845 845 855 850 850 845 835 820 805
ON OFF OFF 1005 1005 1015 1035 1040 1040 1035 1030 1025 1010
ON OFF ON 1190 1200 1200 1205 1205 1215 1205 1200 1185 1170
ON ON OFF 1350 1370 1390 1390 1400 1390 1380 1380 1360 1340
ON ON ON 1350 1370 1390 1390 1400 1390 1380 1380 1360 1340
Maximum Clg Airflow
2
1595 1600 1600 1600 1595 1555 1505 1465 1430 1390
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 680 680 680 675 670
See Note
4
Continuous Fan
Airflow (SW3)
OFF OFF ON 525 520 525 495 475
See Note
4
OFF ON OFF 680 680 680 675 670
See Note
4
OFF ON ON 815 845 845 855 850 850 845 835 820 805
ON OFF OFF 1005 1005 1015 1035 1040 1040 1035 1030 1025 1010
ON OFF ON 1190 1200 1200 1205 1205 1215 1205 1200 1185 1170
ON ON OFF 1190 1200 1200 1205 1205 1215 1205 1200 1185 1170
ON ON ON 1190 1200 1200 1205 1205 1215 1205 1200 1185 1170
Heating (SW1)
High Heat Airflow
3
1190 1205 1210 1210 1210 1210 1210 1210 1210 1200
Low Heat Airflow
3
950 970 985 985 985 985 985 985 985 980
Unit Size: 0902120 Clg/CF Switch Settings External Static Pressure (ESP)
Clg Switches SW2-3 SW2-2 SW2-1 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1785 1805 1815 1835 1840 1855 1860 1850 1845 1835
CF Switches SW3-3 SW3-2 SW3-1
Low-Clg Default: OFF OFF OFF 925 935 945 960 980 965 940 925 920 900
Cooling Airflow
(SW2)
Low-Cooling Airflow
(SW3)
OFF OFF ON 715 715 735 730 730
See Note
4
OFF ON OFF 925 935 945 960 980 965 940 925 920 900
OFF ON ON 1040 1045 1030 1055 1060 1045 1060 1045 1030 1005
ON OFF OFF 1295 1320 1285 1335 1350 1340 1350 1335 1310 1300
ON OFF ON 1505 1525 1480 1480 1490 1475 1465 1455 1450 1445
ON ON OFF 1785 1805 1815 1835 1840 1855 1860 1850 1845 1835
ON ON ON 2250 2265 2270 2265 2255 2245 2220 2175 2120 2060
Maximum Clg Airflow
2
2375 2375 2375 2365 2330 2285 2235 2185 2140 2075
CF Switches SW3-3 SW3-2 SW3-1
Cont. Fan Default: OFF OFF OFF 925 935 945 960 980 965 940 925 920 900
Continuous Fan
Airflow (SW3)
OFF OFF ON 715 715 735 730 730
See Note
4
OFF ON OFF 925 935 945 960 980 965 940 925 920 900
OFF ON ON 1040 1045 1030 1055 1060 1045 1060 1045 1030 1005
ON OFF OFF 1295 1320 1285 1335 1350 1340 1350 1335 1310 1300
ON OFF ON 1505 1525 1480 1480 1490 1475 1465 1455 1450 1445
ON ON OFF 1505 1525 1480 1480 1490 1475 1465 1455 1450 1445
ON ON ON 1505 1525 1480 1480 1490 1475 1465 1455 1450 1445
Heating (SW1)
High Heat Airflow
3
1590 1610 1605 1605 1600 1605 1610 1610 1615 1620
Low Heat Airflow
3
1425 1450 1440 1465 1470 1455 1450 1440 1435 1430
Table 13 – Air Delivery - CFM (With Filter) (Continued)
