Ready:
M5X8 Screw(4Pcs)
Belt(2Pcs)
M5 Square Nut(4Pcs)
Ready:
Profile Cover(4Pcs)
STEP5.Take out 2 belts, put the belts through the two pulleys and the timing
pulley, and fix them with 2 M5*8 screws and M5 square nuts.
STEP6.Take out the 4 profile covers and install them on the profile end faces
at the front and rear ends of the gantry.
Frame Assembly Pt.5
Frame Assembly Pt.6
Diagram of belt installation
To Next Page
