2. Output
Go to “Main Menu”→ “Parameter”→ “Display”→ “Output” to get he interface shown as Fig. 5-5.
Fig. 5-5
3. Private Zone
Go to “Main Menu” → “Parameter” → “Display” → “Private Zone” to enter into the interface shown
as in Fig. 5-6. Privacy Zone is for setting some invisible parts in the selected channel, as shown in
Fig. 5-6 and Fig. 5-7.
1. Select the number of the zone to be set (maximum 4 zones can be set for single channel)
2. Click “Setup” to adjust the position of the zone.
3. After finish setting, right click the mouse to return to the “Privacy Zone” page.
4. Click “Save” to save the setting.
Fig. 5-6 Fig. 5-7
4. Record
Go to “Main Menu” → “Parameter” → “Record” → “Record” to get the interface shown as Fig. 5-8.
Fig. 5-8
Video Output: Live Output
Sequence Mode: Set sequence mode
SEQ Time: Sequence time is set 5 seconds
by default. User may set it as required
VGA/HDMI Resolution: For VGA output or
HDMI output, the optional resolution include
800×600, 1024×768, 1280×1024, 1440×
900, 1280×720, 1920×1080
Transparency: Adjust menu transparency in
the range of 0--128.
Channel: Set the desired channel in the
drop-down menu
Record Switch: Enable/disable record
Pre Record: Enable to pre-record motion
detection or I/O trigger record.
