13. FTP
Go to “Main Menu” → “Parameter” → “Network” → “FTP”
Set IP, User Name and Password to view the captured pictures in the server (See Fig. 5-18).
Fig. 5-18
14. Motion
Go to “Main Menu” → “Parameter” → “Alarm” → “Motion” to get the interface shown as Fig. 5-20
Fig. 5-20
Fig. 5-21
Area: Click it to enter into the interface shown as Fig. 5-21 to set the motion detection area to
be monitored intensively.
A single channel is divided into 15×12 (PAL) or 15×10 (NTSC) configurable grids. The red grids
indicate that the motion detection in the area is enabled, white semitransparent ones indicates
that the motion detection in the area is disabled. After setting is completed, right click the
mouse button to return and click Save to make the parameter setting effective.
Record Channel: When object motion is detected, the record channel setting will be activated.
Channel: Enable or disable Motion function.
Sensitivity: Support 1-8 level, 8 is the
highest level.
Buzzer: When detecting object moving,
buzzer makes alarms (disable, 10 seconds,
20 seconds, 40 seconds and 60 seconds).
Alarm Out: Connect to the alarm switch of
the alarm apparatus.
Show Message: Messages will be displayed
on the screen when moving object is
detected and alarms are made.
Send Email: When moving object is detected,
send Email to the specified Email address.
Full Screen: When moving object is detected,
messages will be displayed in full screen.
Latch Time: When moving object is detected,
the alarm time can be set as 10 seconds, 20
seconds, 40 seconds and 60 seconds.
Post Recording: After the alarm finishes, the
duration time of the alarm recording can be
set as 30 seconds, 1 minute, 2 minutes and 5
minutes.
