2.8 <Floppy Port>
The board provides one slim type floppy port.
FDD
1. Lift up this plastic bar
2. Slot the cable in (Blue paste for outside)
3. Press back the plastic bar
Floppy rear side
4. Lift up the brown plastic bar
5. Slot the cable in (Blue paste for
brown bar side)
6. Press back the plastic bar
