LV-679 User’s Manual
-9-
1.2 <Product Specification>
General Specification
Form Factor Mini-ITX motherboard
CPU Support Intel Core 2 Duo Mobile Processor
Package type: Micro-FCPGA478 (Socket-P)
Front side bus: 533/800 MHz
Memory Two DDRII 533/667MHz DIMM up to 3GB with dual channel
Interleaved mode
Chipset Intel GM(E)965 & ICH8-M (82801HBM)
Real Time Clock Chipset integrated RTC with onboard lithium battery
Watchdog Timer Generates a system reset with internal timer for 1min/s ~ 255min/s
Power Management ACPI 1.0 compliant, supports power saving mode
PCI Enhanced IDE One 44-pin UltraATA33 IDE interface supports up to 2 ATAPI devices
Serial ATA Interface 3 x serial ATAII interface with 300MB/s transfer rate
VGA Interface Intel integrated extreme GMA X3100 (Graphic Media Accelerator)
Technology
Video Memory Up to 384MB shared with system memory
LVDS interface Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V
supply
DVI Interface Two Chrontel CH7307C DVI transmitter with onboard 26-pin DVI
interface
Audio Interface Intel integrated ICH8-M with Realtek ALC888 HD Audio
LAN Interface Two Intel 82573L Gigabit LAN
Solid State Disk IDE supports 44-pin DiskOnModule with +5V/+3.3V power supply,
One Compact Flash Type II
GPIO interface Onboard programmable 8-bit Digital I/O interface
Extended Interface One PCI slot, Two Mini PCI socket to support Mini PCI Type IIIA
Internal I/O Port 1x RS232/422/485, 1x slim FDD port, 1x GPIO port, 1 x Parallel Port,
4 x USB ports, 1x IrDA, 1x IDE, 1x LVDS, 1x LCD inverter connector,
2 x DVI, 1x HDTV, 1x Front panel Audio connector and 1 x CDIN
connector
External I/O Port 1x PS/2 Keyboard/Mouse Port, 2 x RJ45 LAN ports, 1x DB15 VGA port,
4x USB2.0 ports, 2x IEEE 1394 port, 1x RS232 port, 7.1 Channel Audio
Output, 1x SPDIF connector
Power Requirement Standard 20-Pin ATX power supply
or 9~24V full range DC Input ( 8~30V operative)
Dimension 170mm x 170mm
Temperature Operating within 0~60 centigrade
Storage within –20~85 centigrade
To Next Page
