LV-679 User’s Manual
-
26-
2.10.2 <Digital Display>
The board provides one 40-pin LVDS connector for 18/24-bit single/dual channel panels,
supports up to 1600 x 1200 (UXGA) resolution, with one LCD backlight inverter
connector and one jumper for panel voltage setting.
1 5
CN_INV
JVLCD
1
2
5
6
Attention: Don’t short JVLCD odd to odd pin. It could be cause serious damage.
CN_LVDS
1
2
39
40
