Commend EE 8000 - Installation; Measurements

Installation Industrial Stations EE 8000
14 3.1/0614
Installation
Measurements
Measuring units in mm (inch), not scale!
86 (3.39)
173 (6.81)
175 (6.89) / 177 (6.97) with covers
50 (1.97)
No laterial expansion openings at EE 8999MSOS
65 (2.56)
120 (4.72)
312 (12.28)
160 (6.3)
295 (11.61) Mounting bore-hole
60 (2.36)
22
(0.67)
50 (1.97)
65 (2.56)
100 (3.94)
60 (2.36)
50 (1.97)
20
0.79
ø6
ø0.24
2
(0.08)
2
(0.08)
