Configuration CCT 800 Industrial Stations EE 8000
28 3.1/0614
Templates
It is possible to create templates for indication of conversations, call requests, input messages, outputs
and line faults. These can then be advised to the individual LED buttons.
Select “Templates” in the folder of the respective EE 8000:
Combo-boxes “colour“: selection of “red”, “green” or “OFF”
Combo-boxes “blink mode“: selection of “no indication”, “always on”, “slow blinking” or “fast
blinking”
LED Template Conversation indication
Three templates can be defined for conversation indication:
Subscriber
>
Station Properties
>
EE 8000
>
Station
>
Templates
> tab
Conversation indication
In the combo-box Conversation colour a colour can be selected for indication of conversations.
In the combo-box Conversation blink mode the illumination of the buttons can be selected for in-
dication of conversations.
In the combo-box Busy colour a colour can be selected for indication of busy subscribers.
In the combo-box Busy blink mode the illumination of the buttons can be selected for indication of
busy subscribers.
LED Template Call request / Input message
Seven templates can be defined for indication of call requests:
Subscriber > Station Properties > EE 8000 > Station > Templates >
tab Call request / Input message
In the combo-box Call 1/Active 1 colour a colour can be selected for indication of call requests
(call 1).
In the combo-box Call 1/Active 1 blink mode the illumination of the buttons can be selected for
indication of call requests (call 1).
In the combo-box Call 2/Active 2 colour a colour can be selected for indication of emergency calls
(call 2).
In the combo-box Call 2/Active 2 blink mode the illumination of the buttons can be selected for
indication of emergency calls (call 2).
LED Templates Output- / Special- function
Three templates can be defined for indication of outputs:
Subscriber > Station Properties > EE 8000 > Station > Templates >
tab Output- / Special- function
In the combo-box Condition 1 colour a colour for Function 1 can be selected.
In the combo-box Condition 1 blink mode the illumination of the buttons can be selected for
function 1.
In the combo-box Condition 2 colour a colour for Function 2 can be selected.
In the combo-box Condition 2 blink mode the illumination of the buttons can be selected for
function 2.
In the combo-box Condition 3 colour a colour for Function 3 can be selected.
In the combo-box Condition 3 blink mode the illumination of the buttons can be selected for
function 3.
In the combo-box Condition 4 colour a colour for Function 4 can be selected.
In the combo-box Condition 4 blink mode the illumination of the buttons can be selected for
function 4.
