Commend EE 8000 - Mounting Notes; Horizontal Combination of Stations and;or Single Station; Vertical Combination of Stations; Attention

Industrial Stations EE 8000 Installation
3.1/0614 15
Industrial station with microphone module etc.:
Measuring units in mm (inch), not scale!
Mounting Notes
Regardless if a single industrial station or a combination of stations in vertical or horizontal order is
used:
The station(s) shall be mounted in a way, that the microphone is about 1.40 m (4.6 ft) above the floor.
Please adapt the mounting height to the individual needs.
Note: Two expansion housings EE 8999S can be combined with one basic housing EE 8999M.
Horizontal Combination of Stations and/or Single Station
The upper edge of the station(s) about 1.65 m (5.4 ft) from the
finished floor:
The microphone thus is about 1.40 m (4.6 ft) above the floor.
Vertical Combination of Stations
Regardless if a combination of 2 or 3 stations is used:
The microphone shall be located about 1.40 m (4.6 ft) above the
floor.
Attention:
Do not expose the station to extreme temperature (below –20° C or above +70° C / –4° F to 158° F)
