24581-A
IFC OR OSP
CABLE
A
B C
SHEATH
36.0 IN.
(91.44 CM)
110 - 116 IN.
(279 - 295 CM)
SUB-UNITS
FIBERS
BOTH BUNDLES
ROUTED FROM TOP
IFC OSP
IFC OSP
BOTH BUNDLES
ROUTED FROM BOTTOM
ROUTED FROM BOTTOM
OSP
ROUTED FROM TOP
IFC
RADIUS
LIMITER
PLACE GROMMETS
ON EACH RADIUS
LIMITER BEHIND
AND IN FRONT OF
SPLICE TRAYS
CORNER OF
SPLICE TRAYS
ADCP-90-545 • Issue 4 • July 2016
Page 30
© 2016 CommScope. All Rights Reserved.
Figure 26. Routing within 48-Fiber Splicing Wall-Mount Box
