TOP VIEW WITH SPLICE DRAWER CLOSED
TOP VIEW WITH SPLICE DRAWER OPEN
TIE DOWN
USING CORD
LACING
TIE DOWN
USING CORD
LACING
11434-B
PROPER BEND RADIUS
MUST BE MAINTAINED
ADCP-90-545 • Issue 4 • July 2016
Page 7
© 2016 CommScope. All Rights Reserved.
Figure 5. Correct Pigtail Routing within 24-Fiber Termination/Splicing Module
