ComNav 2001 - Remote Heading Displays

ComNav 2001 Autopilot System
P/N 29010017 V1.0 - 25-
INSTALLATION INSTRUCTIONS
REMOTE HEADING DISPLAYS
Up to four optional Remote Heading Displays
can be run by the autopilot. These can be
mounted anywhere convenient using the supplied
bracket. A 4-conductor overall shielded cable is
required.
Refer to the wiring diagram supplied with the
Remote Heading Display to connect the cable
into the autopilot distribution box.
Table II – RECOMMENDED CABLES
USE
TYPE
PILOT POWER
2 X 16 GAUGE
RUDDER DRIVE – SOLENOID VALVE
3 X 18 GAUGE
RUDDER DRIVE – CONTROL BOX
REFER TO THE INSTRUCTIONS SUPPLIED
WITH THE CONTROL BOX
RUDDER FOLLOWER
3 X 18 GAUGE
REMOTE HEADING DISPLAYS
4 X 24 GAUGE W/OVERALL SHIELD
RUDDER ANGLE INDICATOR
4 X 24 GAUGE
NAV INTERFACE
2 X 24 GAUGE W/OVERALL SHIELD.
SHIELD TERMINATED AT AUTOPILOT
ONLY
HEADING OUTPUT (N + 1)
2 X 24 GAUGE W/OVERALL SHIELD.
SHIELD TERMINATED AT AUTOPILOT
ONLY
HEADING OUTPUT (BCD)
3 X 24 GAUGE W/OVERALL SHIELD.
SHIELD TERMINATED AT AUTOPILOT
ONLY
EXTERNAL ALARM
3 X 24 GAUGE
WATCH ALARM
4 X 24 GAUGE
