ComNav 2001 Autopilot System
P/N 29010017 V1.0 - 31-
DIP SWITCHES
The Dip Switches are used to control a number of autopilot functions. The function of the each Dip Switch is summarized in
the following table:
Table III - DIP SWITCH FUNCTIONS
DIP SWITCH FUNCTIONS
SWITCH #
OFF (OPEN)
ON (CLOSED)
1
STD WIND INTERFACE
NMEA WIND INTERFACE
2
NMEA WIND NORMAL
NMEA WIND REVERSED
3
TX PORT CONFIGURE
4
TX PORT CONFIGURE
5
REMOTE 1 NON-TILLER TYPE
REMOTE 1 TILLER TYPE
6
REMOTE 2 NON-TILLER TYPE
REMOTE 2 TILLER TYPE
7
REMOTE 1 NORMAL
CONFIGURATION
ELECTRIC WHEEL CONNECTED
TO REMOTE 1
8
NOT ASSIGNED
9
OPERATING MODE - FACTORY PRESET
10
OPERATING MODE - FACTORY PRESET
11
OPERATING MODE - FACTORY PRESET
12
OPERATING MODE - FACTORY PRESET
Table IV - TX PORT CONFIGURE
TX PORT CONFIGURE
DIP SWITCH
3
4
REMOTE HEADING
OFF
OFF
N+1
ON
OFF
BCD
OFF
ON
NMEA 0183
ON
ON
Further information on the Dip Switches can be found in the section of the manual corresponding to their function.
