ComNav 2001 Autopilot System
P/N 29010017 V1.0 - 5-
REMOTE CONTROL
The autopilot must be turned on at the master
control unit to use any remote control.
Take control at the Remote by pressing both its
pushbuttons for one second. The decimal point on
all displays will move to the REM.1 or REM.2
position. This control operates identically to the
autopilot, except that there is a toggle switch,
used together with one of the pushbuttons, to
dodge or select a U-Turn.
Take control at the Remote by pressing both its
pushbuttons for one second. The decimal point on
all displays will move from the MASTER
position to the REM.1 or REM.2 position. For
direct control of the rudder angle using the lever,
place the toggle switch in the TILLER position.
To begin autopilot control of the vessel on its
present course, place the rotary switch in the
PILOT position . The pushbuttons can be used to
alter the vessels course, either one degree per
push, or, push and hold for 10 degrees per
second.
Take control at the Remote by pressing both its
pushbuttons for one second. The decimal point on
all displays will move to the REM.1 or REM.2
position. The STANDBY, PILOT, and NAV
modes operate identically to the autopilot, except
there is a toggle switch, used together with one of
the pushbuttons, to dodge or select a U-Turn. The
TILLER mode provides direct control of the
rudder angle using the lever.
Take control at the autopilot front panel by
pressing both the red and green ARROW keys
on the autopilot front panel for one second. The
decimal point on all displays will move back to
the MASTER position.
For more complete operating instructions
refer to the REMOTE CONTROLS section.
1. TO USE THE COMNAV 101
REMOTE CONTROL:
2. TO USE THE COMNAV 201
REMOTE CONTROL:
3. TO USE THE COMNAV 211
REMOTE CONTROL:
4. TO TAKE CONTROL AT THE
AUTOPILOT FRONT PANEL:
