Comnet CNGE2+2SMS - Technical Specifications

INS_CNGE2+2SMS_REV– 02/19/13 PAGE 52
INSTALLATION AND OPERATION MANUAL CNGE2+2SMS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Technical Specifications
Technology
Ethernet Standards IEEE 802.3 for 10BASE-T
IEEE 802.3u for 100BASE-TX and 100BASE-FX
IEEE 802.3z for 1000BASE-X
IEEE 802.3ab for 1000BASE-T
IEEE 802.1w for RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1AB for LLDP (Link Layer Discovery Protocol)
IEEE 802.3at for Power Sourcing Equipment (PSE) and PoE (≤ 30 W per port)
IEEE 802.3x Flow Control and Back Pressure
Software Features RSTP (IEEE 802.1D/w)
Port Configuration, Status, Statistics, Security
PoE Configuration, Status, Health Check
SNMP
Enable/Disable Ports
Port Guardian Physical Port Lockout
IGMP Snooping v2
SNMP Trap
LLDP
Static Multicast MAC Routing
Static MAC Lock Security
Active Ping Check with SNMP Trap, Port Reset & Port Shutdown capability
Interface
SFP 2 × 100/1000Base-X SFP
RJ45 Ports 2 × 10/100/1000Base-T(X), Auto MDI/MDIX
LED Indicators Per Unit : Power × 2 (Green)
RJ45 Ports:
Per Port : Link/Activity(Green/Blinking Green), 1000 Mbps indicator (Amber)
SFP Ports:
Per Port : Link/Activity(Green/Blinking Green)
Power Requirements
Power Input Voltage Dual 48 to 57 VDC PoE, 9 to 36 VDC
or 24 VAC non PoE
Current Draw 3.5A max, with PoE, 1A w/out PoE
Reverse Polarity Protection Present (On Terminal Block of Non-PoE Models Only)
Environmental
Operating Temperature -40 to +75 ºC
Storage Temperature -40 to +85 ºC
Operating Humidity 5% to 95%, non-condensing
