Comnet CNGE2+2SMS - Page 9

INS_CNGE2+2SMS_REV– 02/19/13 PAGE 9
INSTALLATION AND OPERATION MANUAL CNGE2+2SMS[POE][HO]
TECH SUPPORT: 1.888.678.9427
12
6 7 8
5
3
2
9
13
1
4
10
11
CNGE2+2SMSPOE
12
6 7 8
5
3
2
9
13
1
4
10
11
CNGE2+2SMSPOEHO
1. Power connections
2. Contact IN terminal block
3. Contact OUT terminal block
4. Configuration DIP switches
5. Console Mini USB
6. LED for Power 1
7. LED for Power 2
8. LED for Status
9. RJ-45 Ports
10. PoE Status LEDs for RJ-45 Port 1
11. PoE Status LEDs for RJ-45 Port 2
12. Link/Activity LEDs for SFP Ports 3 and 4
13. SFP Ports 3 and 4
