Service Reference Guide, dc7700 433612-001 7–23
Removal and Replacement Procedures— Small Form Factor (SFF) Chassis
7.11.2 Optical Drive
Ä
CAUTION: All removable media should be taken out of the drives before removing the drive from the
computer.
✎
An optical drive is a CD-ROM, CD-R/RW, DVD-ROM, DVD+R/RW, or CD-RW/DVD Combo
drive.
1. If you have locked the Smart Cover Lock, use Computer Setup to unlock the lock (Section
7.2).
2. Prepare the computer for disassembly (Section 7.1).
3. Remove the computer cover (Section 7.5).
4. Rotate the drive cage to its upright position by pulling on the green-tabbed lip.
5. Disconnect the power and data cables from the rear of the optical drive.
