Hardware Reference Guide 3–5
Adding System Memory and Upgrading the Internal Hard Drive
Locating the DIMM Slots
Å
WARNING: To reduce the risk of personal injury from hot surfaces,
allow the internal system components to cool before touching.
3. To remove a module, press out on both latches 1 of the DIMM
socket at the same time. This releases the module and partially
pushes it out of the socket.
4. Lift the module from the socket.
sp-hrg.book Page 5 Thursday, December 13, 2001 9:14 AM
