3–6 Hardware Reference Guide
Adding System Memory and Upgrading the Internal Hard Drive
Adding or Removing Memory Modules
5. To install a memory module, press out on both latches 1 of the
DIMM socket at the same time. Match the notch on the module
with the tab on the memory socket. Firmly push the module
straight into the socket 2, ensuring that the module is fully
inserted and properly seated. The latches will close automatically
when the module is seated correctly, securing the module in the
slot 3.
✎
If only one memory module is used in the system, it must be installed
in the same socket that held the preinstalled memory module.
6. Replace the access panel.
✎
When the personal computer starts up, it will recognize the system
memory upgrade and automatically reconfigure the system.
sp-hrg.book Page 6 Thursday, December 13, 2001 9:14 AM
