Removal and Replacement Procedures
Maintenance and Service Guide 5–13
3. Remove the two PM2.5 × 5.0 screws 1 that secure the mini
PCI compartment cover to the base enclosure (Figure 5-7).
4. Lift the left edge of the cover and swing it up and to the
right 2.
5. Remove the cover.
✎
The mini PCI compartment cover is included in the
Miscellaneous Plastics Kit (spare part number 241439-001).
Figure 5-7. Removing the Mini PCI Compartment Cover
279362-003.book Page 13 Monday, May 19, 2003 1:28 PM
