JUMPER & SWITCH INFORMATION
System Board Connectors
Function Description
Video 15-pin VGA
Microphone in Mini stereo
Audio Line out Mini stereo
(2) DIMM sockets 168-pin DIMM
(3) PCI slots 32-bit PCI connector
Line in Mini stereo
LCD Panel (Digital Dashboard) 10 pin header
Battery socket 2-pin socket
IDE drives 40-pin headers, key 20
Diskette drive 34-pin header
Fan with active heatsink 3-pin header
Power supply 20-pin header
