MNC-0500-026 14 of 32 Revision G
Amplifier Communication and Protocol, Rabbit CPU
Parameter Information Requested Response Format
‘%’ Time and Date 16 Bytes: YYYY/MM/DD, hh:mm
“!” Extended Summary
Status
4 bytes
Byte A Summary Status Byte A
Byte B Summary Status Byte B
Byte C Bit 7 -- Reserved
Bit 6 -- compliment of Bit 5
Bit 5 -- BUC Warmup mode*
Bit 4 -- Switch 2 Pos B
Bit 3 -- Switch 2 Pos A
Bit 2 -- automatic mode
Bit 1 -- Waveguide switch 1
other amplifier, or
position ‘B’ in 1-for-2
mode
Bit 0 -- Waveguide switch 1
this amplifier, or
position ‘A’ in 1-for-2
mode
Byte D Bit 7 -- Reserved (Always 0)
Bit 6 -- Compliment of Bit 5
Bit 5 -- IF Drive High
Bit 4 -- UPC Suspended
Bit 3 -- UPC Enabled
Bit 2 -- Mode Selected
Bit 1 -- Mode Selected
Bit 0 -- Mode Selected
*Only on amplifiers with a Smart BUC
installed.
‘#’ Extended Fault Status ABCD
‘(‘ Extended Alarm Status ABCD
‘1’ Summary Status XX
‘3’ Fault Status XX
‘6’ Power XX.X in dBW
‘7’ Power XXXX in Watts
‘8’ Attenuator Setting XXXX counts
‘9’ Alarm Status X
‘A’ Attenuator XX.X in dB
‘H’ High Power Alarm/Fault
Trip point and setting
A XX.X in dBm (generate alarm)
F XX.X in dBm (generate fault)
D XX.X in dBm (disabled)
‘h’ High Power Alarm/Fault
Trip point and setting
A XXXX in Watts (generate alarm)
F XXXX in Watts (generate fault)
D XXXX in Watts (disabled)
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
