MNC-0500-026 15 of 32 Revision G
Amplifier Communication and Protocol, Rabbit CPU
Compatability: The XTC-100D supports the following parameter subset (whenquerying it
for amplifier status): ‘1’, ‘3’, ‘8’, ‘I’, ‘M’, ‘N’, ‘P’, ‘Q’, ‘T’, and ‘V’
Notes:
1. Parameters ‘M’ and ‘N’ are only available for digital HPAs.
2. Redundant Controllers turn around ‘1’, ‘8’, ‘I’, ‘P’, ‘Q’, ‘T’, ‘V’.
3. Dual Path Controllers pass through queries regardless of parameters.
4. Parameters ‘Z’ and ‘z’ are only available with HPAs that have the linearizer option.
5. Parameter ‘/’ is only applicable to Linearizers that have the Magnitude slope adjustment
option.
‘I’ Helix Current -- if you
have a TWTA
Body Current -- If you
have an EIK
XX.X in mA
‘L’ Low Power Alarm/Fault
Trip point and setting
A XX.X in dBm (generate alarm)
F XX.X in dBm (generate fault)
D XX.X in dBm (disabled)
‘l’ Low Power Alarm/Fault
Trip point and setting
A XXXX in Watts (generate alarm)
F XXXX in Watts (generate fault)
D XXXX in Watts (disabled)
‘M’ Heater Hours XXXXXX hours
‘N’ Beam Hours XXXXXX hours
‘P’ Fwd Power XX.X in dBm
‘Q’ Reverse Power XX.X in dBm
‘R’ Reverse Power Alarm/
Fault trip point and
setting
A XX.X in dBm (generate alarm)
F XX.X in dBm (generate fault)
D XX.X in dBm (disabled)
‘r’ Reverse Power Alarm/
Fault Trip point and
setting
XXXX in Watts
‘T’ TWT Temp -- if you have
a TWTA
Tube Temp -- If you have
an EIK
XXXX in degrees Celsius (Right
Justified and Padded with Spaces.)
‘V’ Helix Voltage -- If you
have a TWTA
Geam Voltage -- If you
have an EIK
XX.X in KV
‘Z’ Linearizer Amplitude 0 -- 4095 counts
conversion equation is V=Z* (10/4096)
‘z’ Linearizer Phase 0 -- 4095 counts
conversion equation is V=z*(10/4096)
‘/’ Linearizer Magnitude
Slope setting
XXXX
Parameter Information Requested Response Format
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
