MNC-0500-026 20 of 32 Revision G
Amplifier Communication and Protocol, Rabbit CPU
Miscellaneous Setup
Command Byte: ‘P’
Query: P/?
Returns: P/nXXXX where XXXX is the line slope value; n is the current sub-
band number for that slope.
Examples:
Query: P/?
Returns: P/nXXXX where n is the current sub-band; XXXX is the slope for
that sub-band.
Query: P/?n
/ = Linearizer Slope
n = sub-band number (1-4)
Examples:
Query: P/?1 (Same query fo rsub-bands 2 through 4)
Returns: P/1XXXX where 1 is the first sub-band; XXXX is the slope fo rsub-
band 1. The return meaning is the same for sub-bands 2 through 4.
Query: PC?
Returns: PCx
C = WG Switch mode. x = mode
0 = No Waveguide Switch
1 = One WG Switch for ONE-FOR-ONE redundant mode
2 = One WG Switch for ONE-PLUS-ONE redundant mode
3 = Two WG Switches for ONE-FOR-ONE plus a load switch
4 = 1:2 redundant system with two waveguide switches.
T = Waveguide Arc Test
S = Summary Fault Test
Query: PBCA?
Returns: PBCAxx.x, where xx.x is the IF attenuation in dB.
Query: PBCP?
Returns: PBCPxx.x, where xx.x is the IF input power to the Block Up
Converter in dBm.
Query: PBCT?
Returns: PBCTxx.x, where xx.x is the internal temperature of the Block Up
Converter in degrees C.
Query: PEX<?>
E = Ethernet
X = mode or parameter you wish to query.
D? = Interface Up/Down status.
I? = IP Address
N? = Netmaks
M? = MAC Address
U? = Interface Up/Down status.
Examples:
Query: PED?
Returns: PEDX where X = 1 if interface is Down (disabled) or 0 if interface is
Up (enabled.)
Query: PEU?
Returns: PEUX where X = 0 if interface is Down (disabled) or 1 if interface is
Up (enabled.)
