14 UMC 600IS Installation Manual
Prompt Display Interpretation Notes
Digital Averaging
No.
Averages
Update
Rate
51 1 10/sec
52 2 5/sec
54 4 2.5/sec
58 8 1 sec
516 16 2 sec
532 32 4 sec
5A1 8-4-2 Variable
5A2 16-8-2 Variable
Tare Enable Selection of either fixed tare (Ft) or fixed tare and auto tare (both) in Parameter 6
allows up to a six digit fixed tare entry to be made using the numeric front panel
keys or, when configured for full duplex serial communication, a fixed tare entry
can be down loaded through the serial port.
6 Atnr Auto (stored) tare only
– no recall
6 AUto Auto (stored) tare only
6Ft Fixed (manual) tare
only
6 both Auto or fixed tare
AZM Capture Band (Displayed Grads)
7 oFF Off
7 0.5 ±0.5
71 ±1.0
73 ±3.0
75 ±5.0
710 ±10.0
Table 3-4. Configuration Display Prompts 5 – 7
