Configuration 15
Prompt Display Interpretation Notes
AZM/PAZ Aperature
8 1.9 ±1.9% of full scale
8FS 100% of full scale
Motion Band
9 oFF Off
91 ±1.0
93 ±3.0
95 ±5.0
910 ±10.0
920 ±20.0 Selections available when Option 1 is enabled
950 ±50.0
Display Base (lb/kg)
10 lb lb display only
10 kg kg display only
10 Con lb (base) conversion lb/kg CONV key functions only if Parameter 10 is set to 10 Con
Table 3-5. Configuration Display Prompts 8 –10
Prompt Display Interpretation Notes
11 Setpoint mode Not supported
12 Zero Band Control output Not supported
13 Weighing Mode Not supported
14 Serial Configuration See Section 3.2 on page 16.
Table 3-6. Configuration Display Prompts 11 – 14
