26 UMC 600IS Installation Manual
9. Press 9, 9, 9 and ENT to end this file. To
review the file, press the 2 SET POINT key.
With each press of this key we step back one
line. Check against Table 3-15.
In the GROSS mode, press
PRINT to produce a ticket
in this format:
Figure 3-13. Sample Print from File 7.1
NOTE: If the control code 400 is used in a custom
print, you must enable and set Option 3.
Notice that the sample print format does not exceed 30
lines of code. Now add a company name or logo to the
ticket. We can do this by setting up a MACRO. This
MACRO can be called into any format that is set up
by using the correct Parameter Control Code.
According to the Parameter Control Code Chart, if
this information is to be used in a print format, enter a
code 600 - call Macro 1.
Use the following example:
GLEN CO inc. (line 1)
GLENWOOD MN. (line 2)
Time/Date (line 3)
Format 1: GROSS weight (line 4)
Format 2: GROSS (ln 4), TARE (ln 5), NET (ln 6)
Figure 3-14. Sample Print from File 7.1
Line Number Code Code Definition
01 002 STX (start of text)
02 400 Time and date
03 013 Carriage return (CR)
04 010 Line Feed (LF)
05 200 Gross Wt. “LB/KG GR”
06 013 Carriage Return (CR)
07 010 Line Feed (LF)
08 999 End of file
Table 3-15. Print File 7.1 (7.1, T/D, Gross Wt.)
6:42 PM 04/16/02
8594 LB GR
Line Number Code Code Definition
01 002 STX (start of text)
02 600 call MACRO 1 (File 7.9)
03 400 Print Time and Date
04 013 Carriage return
05 010 Line feed
06 200 Gross wt. “LB/KG GR”
07 013 Carriage return
08 010 Line feed
09 999 END OF FILE
Table 3-16. Print File 7.1 Example (7.1, Co. Logo, T/D,
Gross Wt.)
Line Number Code Code Definition
01 002 STX (start of text)
02 600 call MACRO 1 (File 7.9)
03 400 Print Time and Date
04 013 Carriage return
05 010 Line feed
06 220 Gross wt. “LB/KG GR”
07 013 Carriage return
08 010 Line feed
09 220 Tare wt. “LB/KG TR”
10 013 Carriage return
11 010 Line feed
12 210 Net wt. “LB/KG NT”
13 013 Carriage return
14 010 Line feed
15 999 END OF FILE
Table 3-17. Print File 7.2 Example (7.2, Co. Logo, T/D,
GR, TR, NT)
GLEN CO inc.
GLENWOOD MN.
10:22 PM 04/16/02
10000 LB GR
