Condec UMC 600IS - Page 44

Appendix 41
Figure 6-1. Standard Unit Dimensions
CAPACITY
ZERO
NET
GROSS
lb
kg
MOTION
FRONT VIEW
9.12
OPTIONAL PANEL
MOUNTING KIT
6.62
.74
4.14
PANEL THICKNESS
.03 THRU .75
.70
3.94
6.35
SIDE VIEW
R
®
REAR VIEW
MODEL NO.
SER. NO.
INPUT VOLTAGE
ADD'L INFO
DATE
VAC 50/60 Hz
SCALE ACCESSORY
LR47913
790F
LISTED
J1
J2
J3
ON/OFF
.56
2X .28
2.26
2X .50
1.22
6.00
3.69
8X R
TILT STAND
