42 UMC 600IS Installation Manual
Figure 6-2. Battery-Powered Unit Dimensions
3.69
2.26
2X .28
.56
2X .50
6.00
1.22
8X R
TILT STAND
OR BATTERY ASSEMBLY 31215. INSTALL PER RLWS DWG 33476.
CLASS II DIV. 1 GROUP E, F, G AND CLASS III WHEN USED WITH POWER SUPPLY
INTRINSICALLY SAFE FOR CLASS I DIV. 1 GROUP A, B, C, D AND
31221/31222,
9.12
11.36
4.26
6.62
.70
BATTERY MODULE
