7. TECHNICAL PARAMETERS
7.4 Technical parameters of processor
32b ARM mikroprocesor
Memory 512 Mb DDR SDRAM
128 Mb FLASH
1 Mb MRAM
Interface Serial interface RS232
Ethernet interface 10/100 Mbit/s
USB 2.0 interface
Table 15: Technical parameters of processor
7.5 Technical parameters I/O por t
I/O port
Input/Output Binary input
Binary output
Reed contact with trigger level 1,3 up to 1,4 V
100 mA / max. 30 V
Table 16: Technical parameters I/O port
7.6 Technical parameters of expansion port
Technical parameters of the expansion ports are specified in separate manuals for expan-
sion ports.
27
