3-4 Operator Panel and Indicators
Original’s Insertion Slot and Ruler
The original’s insertion slot shown below is marked with a
measurement ruler from 0 to 8.5. The units correspond to the scan-
width setup options in the WIDEimage scanning application dialogs. A
a second centered ruler is positioned on top, for optional centered
paper loading with standard sizes.
0
DIAGNOSTIC
POWER
WAIT
1.0 2.0 4.03.0 5.0 6.0 7.0 8.0
0 1.0
8.0
Figure 3-2 Original's Insertion Slot and Ruler
