9
6.
IR Out 1-8—3.5 mm phone jacks for up to 8
IR sticky emitters that can be placed over IR
readers on media players, TVs, or other
targets to transmit IR signal from Media
Controller to the target.
7.
Video Sense Loop In-Out (pairs) 1-4—
Composite port pairs for up to 4 video
sources, such as DVD players or VCRs, that
allow the system to detect the On/Off status
of devices that use the same IR code for both
On and Off commands.
8.
Ethernet—RJ-45 for a 10/100 Baset
Ethernet connection.
9.
USB—USB port for a card reader or other
USB device.
10.
Modem—RJ-11 port for modem to support
caller ID or voice menu system (hardware
foundation for future releases).
11.
Digital Audio In/Out—Toslink for Digital
Audio In/Audio Out, like MP3 players.
12.
Audio In (Left-Right pairs) 1-3—RCA jack for
stereo channel input for up to 3 stereo analog
sources.
13.
Audio Out (Left-Right pairs) 1-3—RCA jack
for stereo channel line output for up to 3
amplifiers.
14.
Video Out Options—Composite, S-Video,
Component, and VGA port for displaying
navigation menus on a monitor or TV.
15.
Power plug port—For supplied power cord
only.
