4.4 I/O specification
The control circuits are isolated from the power circuits in the drive by basic insulation
(single insulation) only. The installer must ensure that the external control circuits are
insulated from human contact by at least one layer of insulation (supplementary
insulation) rated for use at the AC supply voltage.
WARNING
If the control circuits are to be connected to other circuits classified as Safety Extra Low
Voltage (SELV) (e.g. to personal computer), an additional isolating barrier must be
included in order to maintain the SELV classification.
WARNING
See Pr 05 on page 21 (Drive configuration) for terminal set-up diagrams and details.
NOTE
T1
0V common
T2
Analog input 1 (A1), either voltage or current
Voltage: Current input 0 to 10V: mA as parameter range
Parameter range 4-20, 20-4, 0-20, 20-0, 4-.20, 20-.4, VoLT
Scaling
Input range automatically scaled to Pr 01 Minimum set
speed / Pr 02 Maximum set speed
Input impedance 200Ω (current): 100kΩ (voltage)
Resolution 0.1%
T3
+10V reference output
Maximum output current 5mA
T4
Analog input 2 (A2), either voltage or digital input
Voltage: Digital input 0 to +10V: 0 to +24V
Scaling (as voltage input)
Input range automatically scaled to Pr 01 Minimum set
speed / Pr 02 Maximum set speed
Resolution 0.1%
Input impedance 100kΩ (voltage): 6k8 (digital input)
Normal threshold voltage (as digital input) +10V (positive logic only)
T5
Status relay - Drive healthy (Normally open)
T6
Voltage rating 240Vac/30Vdc
Current rating 2A/6A (resistive)
Contact isolation 1.5kVac (over voltage category II)
Operation of contact
OPEN
AC supply removed from drive
AC supply applied to drive with drive in tripped condition
CLOSED
AC supply applied to drive with drive in a 'ready to run' or
'running' condition (not tripped)
Provide fuse or other over-current protection in status relay circuit.
WARNING
