Commander SK Getting Started Guide 43
Issue Number: 1 www.controltechniques.com
Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad
and Display
Parameters
Quick Start
Commissioning
Diagnostics Options
Parameter
List
UL Listing
Information
10 Parameter List
Par Description
Default
Setting 1 Setting 2
EUR USA
01 Minimum set speed (Hz) 0.0
02 Maximum set speed (Hz) 50.0 60.0
03 Acceleration rate (s/100Hz) 5.0
04 Deceleration rate (s/100Hz) 10.0
05 Drive configuration AI.AV
06 Motor rated current (A) Drive rating
07 Motor rated speed (rpm) 1500 1800
08 Motor rated voltage (V) 230 / 400 230 / 460
09 Motor power factor (cos ϕ)0.85
10 Parameter access L1
11 Start/Stop logic select 0 4
12 Brake enable diS
13
Not used
14
15 Jog reference (Hz) 1.5
16 Analog 1 input mode (mA) 4-.20
17 Enable negative preset speeds OFF (0)
18 Preset speed 1 (Hz) 0
19 Preset speed 2 (Hz) 0
20 Preset speed 3 (Hz) 0
21 Preset speed 4 (Hz) 0
22 Load display units Ld
23 Speed display units Fr
24 Customer defined scaling 1.000
25 Security set-up 0
26 Not used
27 Power up keypad reference 0
28 Parameter cloning no
29 Load defaults no
30 Ramp mode select 1
31 Stopping mode select 1
32 Variable torque select OFF (0)
33 Catch a spinning motor select 0
34 Terminal B7 mode select dig
35 Digital output function (terminal B3) n=0
36 Analog output function (terminal B1) Fr
37 Maximum switching frequency (kHz) 3
38 Autotune 0
39 Motor rated frequency (Hz) 50.0 60.0
40 Number of poles Auto
41 Voltage mode selector Ur I
42 Low frequency voltage boost (%) 3.0
43 Serial communications baude rate 19.2
44 Serial address 1
45 Software version
46 Brake release current threshold (%) 50
47 Brake applied current threshold (%) 10
48 Brake release frequency (Hz) 1.0
49 Brake applied frequency (Hz) 2.0
50 Pre-brake release delay (s) 1.0
51 Post brake release delay (s) 1.0
52 Fieldbus node address 0
53 Fieldbus baude rate 0
54 Fieldbus diagnostics 0
55 Last trip 0
